Scion FR-S I (2012-2016) ignition key code cylinder light ind ill+ Wiring diagram
This page shows the only wiring diagram for the component.ignition key code cylinder light ind ill+, which is found in the car Scion FR-S I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition key code cylinder light ind ill+ (1 of 1)
19 18 CANH CANL
AGND
ASSEMBLY (IGNITION SWITCH LOCK CYLINDER ASSEMBLY) (ON STEERING COLUMN)
BLK WIRE
BLK/PNK WIRE
BLK/YEL WIRE
BLU/RED WIRE
BMPX
BRN WIRE
BRN/WHT WIRE
CAN DRIVER
CODE
COMBINATION METER ASSEMBLY
COMPT)
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (RIGHT END OF DASH)
ECU-ACC FUSE
ECU-B FUSE
ENGINE ROOM
FUSE
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HAZ FUSE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC 1 RELAY ENERGIZED
IGNITION KEY CODE CYLINDER LIGHT IND ILL+
ILL
IMO
IND
INSTRUMENT PANEL JUNCTION BLOCK (LEFT END OF DASH)
KSWB
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MPX-B FUSE
ORG/ WIRE
PNK WIRE
POWER CIRCUIT
POWER DISTRIBUTION SYSTEM
R/B, J/B (RIGHT FRONT OF ENGINE
RED WIRE
RED/WHT WIRE
RELAY ENERGIZED
SECURITY IND
TRANSPONDER KEY AMPLIFIER (ON STEERING COLUMN)
TRANSPONDER KEY COIL
TRANSPONDER KEY ECU (IF EQUIPPED) (CENTER OF DASH)
TXCT
UART
UN-LOCK WARNING SWITCH
VIO WIRE
W/O TIRE PRESSURE WARNING SYSTEM
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Immobilizer circuit -> IGNITION KEY CODE CYLINDER LIGHT IND ILL+
