Scion FR-S I (2012-2016) hot at all times engine room Wiring diagrams
This page contains all the electrical diagrams for the component. hot at all times engine room, in which he is found in the car Scion FR-S I (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hot at all times engine room (1 of 2)
ALT FUSE
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/WHT WIRE
CDS FUSE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR (BEHIND RADIATOR)
COOLING FAN MOTOR-2 (BEHIND RADIATOR)
ECM (ENGINE CONTROL MODULE) (RIGHT END OF DASH)
ECU- IG 1 FUSE
EFI ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE)
FAN 1
FAN 1 RELAY
FAN 2
FAN 2 RELAY
FAN 3 RELAY
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HEATER FUSE
HOT AT ALL TIMES ENGINE ROOM
HOT AT ALL TIMES FUSIBLE LINK BLOCK (ON BATTERY POST)
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT END OF DASH)
ORG/ WIRE
R/B, J/B (RIGHT FRONT OF ENGINE COMPT)
RDI FUSE
RED/YEL WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Cooling fan circuit -> HOT AT ALL TIMES ENGINE ROOM
Wiring diagram hot at all times engine room (2 of 2)
ALT FUSE
AMBIENT TEMPERATURE SENSOR (BEHIND RIGHT
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
CDS FUSE
COOLING FAN MOTOR (BEHIND RADIATOR)
COOLING FAN MOTOR-2 (BEHIND RADIATOR)
ECU- IG 1 FUSE
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES ENGINE ROOM
HOT AT ALL TIMES FUSIBLE LINK BLOCK (ON BATTERY POST)
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT END OF DASH)
R/B, J/B (RIGHT FRONT OF ENGINE COMPT)
RDI FUSE
RED/YEL WIRE
SIDE OF FRONT FASCIA)
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (3 of 3) -> HOT AT ALL TIMES ENGINE ROOM
