Scion FR-S I (2012-2016) ecc sup Wiring diagram
This page shows the only wiring diagram for the component.ecc sup, which is found in the car Scion FR-S I (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecc sup (1 of 1)
28 29 CANL CANH
5 1 6 4 KLS+
BKUP LP FUSE
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/YEL WIRE
CAN L
CERTIFICATION ECU ASSEMBLY (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
ECC SUP
ECU-ACC FUSE
GRN WIRE
GRN/YEL WIRE
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
M+(M)
MAIN BODY ECU
MM- M-MODE
ORG/ WIRE
PADDLE SHIFT SWITCH DOWN UP
PARK SWITCH 2 3 STR
PARK/NEUTRAL POSITION SWITCH (ON TRANSMISSION)
PNK WIRE
RED WIRE
RED/BLU WIRE
ROLL SDN CONNECTOR
SFTD
SFTU
SFTU+ UP-SHIFT
SHIFT LOCK RELEASE BUTTON COVER (W/O SMART ENTRY, START SYSTEM)
SHIFT POSITION INDICATOR
SLS+
SOLENOID
STR SLS+ CANH CANL
TRANSMISSION CONTROL MODULE (LEFT SIDE OF DASH)
TRANSMISSIONS SYSTEM
W/ SMART ENTRY, START SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Shift interlock circuit -> ECC SUP
