Rear wiper/washer circuit for Saturn VUE II (2007-2009)
Rear wiper/washer circuit
ACCESSORY VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
DK GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
LIFTGATE AJAR SW SIG
LIFTGATE AJAR SWITCH
LIFTGATE LATCH ASSEMBLY
LOGIC
PNK/BLK WIRE
REAR WINDOW WIPER CONTROL MODULE
REAR WINDOW WIPER SW SIG
REAR WINDSHIELD WASHER FLUID PUMP
REAR WINDSHIELD WIPER/WASHER SWITCH
REAR WPR FUSE
RED WIRE
RED/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
