Satellite radio circuit for Saturn VUE II (2007-2009)
Satellite radio circuit
9 1 2 10 AUDIO OUT(-) L AUDIO SIG (+) R AUDIO SIG (+) RH AUDIO SIG
AIRCON FUSE
BARE
BARE (BLUNT CUT SHIELD)
BARE DRAIN WIRE
BATTERY
BLK/WHT WIRE
BRN/WHT WIRE
COAX
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO RECEIVER
DK GRN WIRE
DK GRN/WHT WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
RADIO
RADIO ANTENNA
RED WIRE
RED/WHT WIRE
TAN/WHT WIRE
WHT WIRE
