2.4l vin p, compressor circuit, with manual a/c for Saturn VUE II (2007-2009)
2.4l vin p, compressor circuit, with manual a/c
19 14 LOW REF
3.5L (VIN N) 2.4L (VIN P)
30 8 65 25 63 13 34 12 CLUTCH RLY CTRL LOW REF
9 12 5 SENS SIG LOW REF SERIAL DATA
A/C CLUTCH FUSE
A/C CLUTCH RELAY
A/C COMPRESSOR CLUTCH
A/C ON IND
A/C ON SWITCH
A/C REFRIGERANT PRESSURE SENSOR (IN A/C HIGH SIDE PRESSURE LINE)
AMBIENT AIR TEMPERATURE SENSOR (BEHIND FRONT GRILLE)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER INFORMATION CENTER (DIC)
ENG-3 FUSE
ENGINE CONTROL MODULE (ECM) (2.4L (VIN P): LEFT REAR OF ENGINE COMPT)
EVAPORATOR TEMPERATURE SENSOR (REAR OF EVAPORATOR CORE)
GRY WIRE
HOT AT ALL TIMES
HOT W/ MAIN RELAY ENERGIZED
HVAC CONTROL MODULE
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
ORG/BLK WIRE
PRESS SENS SIG
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
