Saturn VUE II (2007-2009) veh speed sig Wiring diagram
This page shows the only wiring diagram for the component.veh speed sig, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram veh speed sig (1 of 1)
AUDIO FUSE
BLK/WHT WIRE
COAX NAVI ANTENNA
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (NEAR LEFT FRONT SHOCK TOWER)
HOT AT ALL TIMES
I/P FUSE BLOCK
NAVIGATION ANTENNA
RADIO
RED WIRE
RED/WHT WIRE
SERIAL DATA BATTERY VOLT GND 1 8
VEH SPEED SIG
VSS
WHT WIRE
Go to component -> Navigation circuit -> VEH SPEED SIG
