Saturn VUE II (2007-2009) trailer connector adapter Wiring diagram
This page shows the only wiring diagram for the component.trailer connector adapter, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer connector adapter (1 of 1)
BLK WIRE
BLOCK
BRN WIRE
DK GRN WIRE
HOT AT ALL TIMES
HOT W/ PARK LAMP RELAY 9 ENERGIZED
I/P FUSE
LH TRAILER TURN SIG LP
LOGIC BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
ORG/ WIRE
RED WIRE
RED/WHT WIRE
RH TRAILER TURN SIG LP
TRAILER CONNECTOR
TRAILER CONNECTOR ADAPTER
TRAILER STOP/TURN FUSE
TRLR T/LAMP FUSE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Trailer tow circuit -> TRAILER CONNECTOR ADAPTER
