Saturn VUE II (2007-2009) t/lamp lt fuse Wiring diagram
This page shows the only wiring diagram for the component.t/lamp lt fuse, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram t/lamp lt fuse (1 of 1)
1 2 6 LP SPLY VOLT LP SPLY VOLT LP SPLY VOLT
1 3 5 BAT POS VOLT BAT POS VOLT LP SPLY VOLT
13 12 CONTACT SIG I/P DIMMING
19 16 15 2144 1415 1414 HAZ SW SIG RH SW SIG LH SW SIG
3.6L, 2.4L (VIN P)
4 24 LP SPLY VOLT LP SPLY VOLT
7062 812 PPL
BACKUP LAMPS CIRCUIT
BLK WIRE
COIL SPLY VOLT
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
EXCEPT 3.6L, 2.4L (VIN P)
HAZARD SWITCH
HOT AT ALL TIMES
HOT AT ALL TIMES BCM FUSE (W/ CHROME BUMPER)
HOT AT ALL TIMES BCM FUSE (W/ HOT WEATHER PROVISION)
HOT W/ RUN/ CRNK RELAY ENERGIZED I/P FUSE BLOCK CLUSTER FUSE
I/P MULTI-FUNCTION SWITCH
IGN
LEFT FRONT
LEFT PARK/ TURN SIGNAL LAMP
LEFT REAR
LEFT REAR LAMPS
LEFT REAR TURN SIGNAL LAMP
LEFT TAIL/ STOP LAMP
LEFT TURN
LEFT TURN IND
LH RH
LICENSE LAMP
LOGIC BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
LT BLU/WHT WIRE
MARKER LAMP
ORG/WHT WIRE
PARK LAMP RELAY 9
PARK LPS SIG
PNK WIRE
PPL
PPL/WHT WIRE
RED/WHT WIRE
RIGHT TURN IND
SER DATA
SIGNAL REPEATER LAMP
T/LAMP LT FUSE
TAN WIRE
TO T/LAMP RT FUSE (DIAGRAM 2 OF 2)
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> T/LAMP LT FUSE
