Saturn VUE II (2007-2009) theft deterrent module (left side of Wiring diagram
This page shows the only wiring diagram for the component.theft deterrent module (left side of, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram theft deterrent module (left side of (1 of 1)
17 16 HI SPD GMLAN SER DATA BUS- HI SPD GMLAN SER DATA BUS+
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF
BUS -
BUS+ BUS- BUS-
DIGITAL RADIO RECEIVER (IF EQUIPPED)
DK GRN WIRE
EXCEPT HYBRID W/ 4 SPEED A/T
HVAC CONTROL MODULE
HYBRID W/ 4 SPEED A/T
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) SENSOR
INFLATABLE RESTRAINT VEHICLE ROLLOVER SENSOR (UNDER FLOOR CONSOLE)
INSTRUMENT PANEL
INSTRUMENT PANEL CLUSTER (IPC)
LO SPD GMLAN SER DATA
LT BLU WIRE
NCA WIRE
POWER STEERING ENABLE CONTROL MODULE (PSCM) (ON BOTTOM OF STEERING COLUMN)
RADIO
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
TAN WIRE
TAN/BLK WIRE
THEFT DETERRENT MODULE (LEFT SIDE OF
W/ ONSTAR
Go to component -> Computer data lines circuit (2 of 2) -> THEFT DETERRENT MODULE (LEFT SIDE OF
