Saturn VUE II (2007-2009) roll over sens high signal Wiring diagram
This page shows the only wiring diagram for the component.roll over sens high signal, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roll over sens high signal (1 of 1)
AIR BAG SEAT BELT IND IND
B+ GMLAN SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
DATA LINK CONNECOTR (DLC)
DK GRN WIRE
DK PPL
DRIVER INFORMATION CENTER (DIC) DISPLAY
DRIVER SEAT BELT RETRACTOR PRETENSIONER
DRIVER SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
GMLAN SERIAL DATA
GRN WIRE
GROUND
I/P MULTI-FUNCTION SWITCH
IGN
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE (UNDER FRONT
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INFLATABLE RESTRAINT VEHICLE ROLLOVER SENSOR (UNDER FLOOR CONSOLE)
INSTRUMENT PANEL CLUSTER (IPC) LOGIC
LEFT INFLATABLE RESTRAINT ROOF RAIL MODULE (BEHIND HEADLINER, ABOVE DRIVER)
LT BLU WIRE
NCA WIRE
OFF IND
ON IND.
ORG/ WIRE
ORG/GRN WIRE
PASS AIR AIR SEAT BAG BAG BELT OFF ON IND IND IND GROUND
PASSENGER INFLATABLE RESTRAINT SEAT BELT TENSION SENSOR
PASSENGER SEAT BELT IND
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
PASSENGER SEAT BELT SWITCH
PASSENGER'S SEAT)
PNK WIRE
PNK/ DK WIRE
PPL
PPL DK DK
PPL/ORG WIRE
PPL/WHT WIRE
RED/WHT WIRE
ROLL OVER SENS HIGH SIGNAL
SHORTING BAR
SHORTING BAR PPL PPL/
STAGE 1
STAGE 2
TAN WIRE
TAN/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> ROLL OVER SENS HIGH SIGNAL
