Saturn VUE II (2007-2009) rly ctrl low spd wiring diagram
This page shows the only wiring diagram for the component.rly ctrl low spd, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rly ctrl low spd wiring diagram (1 of 1)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
ECT SENS SIG
ENGINE CONTROL MODULE (ECM)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT SIDE OF FRONT CYLINDER HEAD)
ENGINE COOLING FAN
ENGINE COOLING FAN RESISTOR
FAN AUX FUSE
FAN AUX RELAY
FAN CNTRL RELAY
FAN MAIN FUSE
FAN MAIN RELAY
GRY WIRE
HI SPD
HOT AT ALL TIMES
LOW REF
LT BLU WIRE
RLY CTRL
RLY CTRL LOW SPD
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> 2.4l vin z, engine compartment cooling fan circuit -> RLY CTRL LOW SPD
