Saturn VUE II (2007-2009) right rear lamps Wiring diagrams
This page contains all the electrical diagrams for the component. right rear lamps, in which he is found in the car Saturn VUE II (2007-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear lamps (1 of 2)
BACKUP LP SPLY VOLT
BAT POS VOLT
BCM FUSE 12
BLK WIRE
EARLY PRODUCTION LATE PRODUCTION
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
LEFT BACKUP LAMP
LEFT REAR LAMPS
LEFT REAR TURN SIGNAL LAMP
LOGIC
LOGIC BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
LP SPLY VOLT
LT GRN WIRE
LUGGAGE COMPT)
RED/WHT WIRE
RIGHT BACKUP LAMP
RIGHT REAR LAMPS
RIGHT REAR TURN SIGNAL LAMP
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> Backup lamps circuit -> RIGHT REAR LAMPS
Wiring diagram right rear lamps (2 of 2)
2.4L (VIN P)
2.4L (VIN P), 2.4L (VIN Z)
3.5L
3.6L, 2.4L (VIN Z)
BACKUP LAMPS CIRCUIT
BEHIND HEADLIGHT)
BLK WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DK BLU/WHT WIRE
DK GRN WIRE
FROM T/LAMP LT FUSE (DIAGRAM 1 OF 2)
HEADLAMP SWITCH AUTO PARK OFF HEAD
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
LAMP
LP SW SIG
LP SW SIG 3.5L, 3.6L
LT BLU WIRE
MARKER LAMP
ORG/WHT WIRE
PPL
RIGHT FRONT
RIGHT PARK/
RIGHT REAR
RIGHT REAR LAMPS
RIGHT REAR TURN SIGNAL
RIGHT TAIL/ STOP LAMP
RIGHT TURN
SIGNAL REPEATER LAMP
STOP LIGHT SWITCH (ON BRAKE PEDAL BRACKET)
STOP LP FUSE
STOP LP RELAY 2
T/LAMP RT FUSE
TURN SIGNAL LAMP
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> RIGHT REAR LAMPS
