Saturn VUE II (2007-2009) right front marker lamp Wiring diagram
This page shows the only wiring diagram for the component.right front marker lamp, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front marker lamp (1 of 1)
2.4L (VIN Z)
3.5L
3.6L
BATTERY
BATTERY CURRENT SENSOR
BEHIND HEADLIGHT)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
DEFOGGER RELAY 1
ENGINE CONTROL MODULE (ECM)
EXCEPT HYBRID
FAN MAIN RELAY
IGNITION COIL/ MODULE 1
IGNITION IGNITION COIL/ COIL/ MODULE 5 MODULE 3
LEFT FRONT MARKER LAMP
LEFT HEADLAMP
LEFT HIGH BEAM HEADLAMP
LEFT HORN
LEFT LOW BEAM HEADLAMP
LEFT PARK/TURN SIGNAL LAMP
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
MASS AIR FLOW(MAF) SENSOR/ INTAKE AIR TEMPERATURE (IAT) SENSOR
NCA WIRE
PARK/ NEUTRAL POSITION (PNP) SWITCH
REAR FRONT WINDSHIELD WINDSHIELD WASHER WASHER FLUID FLUID PUMP PUMP
RELAY 5
RIGHT FRONT MARKER LAMP
RIGHT HEADLAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
RIGHT PARK/TURN SIGNAL RIGHT LAMP HORN
RUN WIRE
STARTER GENERATOR CONTROL MODULE (SGCM)
STARTER RELAY 5
STARTER RELAY 6
STOP LAMP RELAY 2
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WINDSHIELD WASHER FLUID LEVEL SWITCH
WPR CNTRL RELAY 10
Go to component -> Ground distribution circuit (1 of 4) -> RIGHT FRONT MARKER LAMP
