Saturn VUE II (2007-2009) passenger heated seat cushion Wiring diagram
This page shows the only wiring diagram for the component.passenger heated seat cushion, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger heated seat cushion (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 IGN 3 VOLT B+ ELEMENT CTRL
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER HEATED SEAT BACK
DRIVER HEATED SEAT CONTROL MODULE (UNDER DRIVER'S SEAT)
DRIVER HEATED SEAT CUSHION
DRIVER HEATED SEAT SWITCH
FUSE
GND LOW REF SENS SIG HI IND CTRL MED IND CTRL
GND LOW REF TEMP SENS SIG HI IND CTRL MED IND CTRL PNK WIRE
GRY WIRE
HEATED SEAT SWITCH
HIGH HEAT IND
HOT AT ALL TIMES
HOT W/ RUN RELAY 14 ENERGIZED
HTD/SEAT FUSE
I/P FUSE BLOCK
ILL
LO IND CTRL
LOW HEAT IND
LOW IND CTRL
LT BLU WIRE
LT GRN WIRE
MEDIUM HEAT IND
PASSENGER HEATED SEAT BACK
PASSENGER HEATED SEAT CONTROL MODULE (UNDER PASSENGER SEAT)
PASSENGER HEATED SEAT CUSHION
PASSENGER HEATED SEAT SWITCH
PNK WIRE
RED/WHT WIRE
RUN WIRE
SEAT SW SIG
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Heated seats circuit -> PASSENGER HEATED SEAT CUSHION
