Saturn VUE II (2007-2009) left rear window switch dn up Wiring diagram
This page shows the only wiring diagram for the component.left rear window switch dn up, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear window switch dn up (1 of 1)
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIV P/WIN FUSE
DRIVER WINDOW MOTOR (IN LEFT FRONT DOOR)
DRIVER WINDOW SWITCH
EXPRESS DOWN SWITCH
HOT W/ ACC/RAP RELAY ENERGIZED
I/P FUSE BLOCK
LEFT FRONT
LEFT REAR
LEFT REAR WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR WINDOW SWITCH DN UP
LT BLU WIRE
LT GRN WIRE
PASS P/WIN FUSE
PASSENGER WINDOW MOTOR (IN RIGHT FRONT DOOR)
PASSENGER WINDOW SWITCH
PPL
PPL PPL
RIGHT FRONT
RIGHT REAR
RIGHT REAR WINDOW MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR WINDOW SWITCH UP DN
TAN WIRE
WINDOW LOCKOUT SWITCH
YEL WIRE
Go to component -> Power windows circuit -> LEFT REAR WINDOW SWITCH DN UP
