Saturn VUE II (2007-2009) ign volt ign volt b+ pnk Wiring diagram
This page shows the only wiring diagram for the component.ign volt ign volt b+ pnk, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign volt ign volt b+ pnk (1 of 1)
ACCELERATOR PEDAL POSITION (APP) SENSOR (ON ACCELERATOR PEDAL LINKAGE ARM)
AIR CONDITIONING SYSTEM COOLING FANS 459 473 1310
APP SEN 1 SIG FTP SENS SIG APP SENS 2 SIG
BRN WIRE
BRN/WHT WIRE
CLUTCH RLY CTRL COOLING FAN RLY CTRL VENT SOLENOID CTRL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM/ TCM/ SGCM FUSE
ENG 1 FUSE ECM FUSE
ENG 2 FUSE
ENG-3 FUSE
ENGINE CONTROL MODULE (ECM)
FUEL LEVEL SENS SIG FUEL LEVEL SENS SIG
GRY WIRE
HOT AT ALL TIMES
IGN VOLT IGN VOLT B+ PNK WIRE
KNOCK SENSOR (KS) 1
KNOCK SENSOR (KS) 2
LOW REF
LOW REF LOW REF PPL
LT BLU WIRE
MIL CTRL FUEL PUMP RLY
PNK WIRE
PNK/BLK WIRE
POWERTRAIN RLY
PPL
PPL/WHT WIRE
PWR/TRN RELAY 6
RED/WHT WIRE
STARTER RLY COIL CTRL
STARTING/ CHARGING SYSTEM
STOP LP SPLY VOLT
SYSTEM
TAC MOTOR CTRL 1 TAC MOTOR CTRL 2 IGN VOLT CAM PHASER 2 CTRL CAM PHASER 4 CTRL
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
THROTTLE ACTUATOR CONTROL (TAC) MODULE (FRONT TOP CENTER OF ENGINE)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.6l vin 7, engine controls circuit (1 of 6) -> IGN VOLT IGN VOLT B+ PNK WIRE
