Saturn VUE II (2007-2009) hot w/ acc/rap relay energized Wiring diagrams
This page contains all the electrical diagrams for the component. hot w/ acc/rap relay energized, in which he is found in the car Saturn VUE II (2007-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hot w/ acc/rap relay energized (1 of 2)
Go to component -> Power mirrors circuit -> HOT W/ ACC/RAP RELAY ENERGIZED
Wiring diagram hot w/ acc/rap relay energized (2 of 2)
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIV P/WIN FUSE
DRIVER WINDOW MOTOR (IN LEFT FRONT DOOR)
DRIVER WINDOW SWITCH
EXPRESS DOWN SWITCH
HOT W/ ACC/RAP RELAY ENERGIZED
I/P FUSE BLOCK
LEFT FRONT
LEFT REAR
LEFT REAR WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR WINDOW SWITCH DN UP
LT BLU WIRE
LT GRN WIRE
PASS P/WIN FUSE
PASSENGER WINDOW MOTOR (IN RIGHT FRONT DOOR)
PASSENGER WINDOW SWITCH
PPL
PPL PPL
RIGHT FRONT
RIGHT REAR
RIGHT REAR WINDOW MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR WINDOW SWITCH UP DN
TAN WIRE
WINDOW LOCKOUT SWITCH
YEL WIRE
Go to component -> Power windows circuit -> HOT W/ ACC/RAP RELAY ENERGIZED
