Saturn VUE II (2007-2009) headlamp switch inside fog air lamp temperature switch sensor wiring diagram
This page shows the only wiring diagram for the component.headlamp switch inside fog air lamp temperature switch sensor, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
headlamp switch inside fog air lamp temperature switch sensor wiring diagram (1 of 1)
2.4L (VIN P)
2.4L (VIN Z)
6 SPEED A/T
A/C COMPRESSOR CLUTCH
AMBIENT LIGHT/ SUNLOAD SENSOR
AUTOMATIC A/C
AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR CONTROL MODULE
BODY CONTROL MODULE(BCM)
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR (DLC)
DIGITAL VIDEO DISC INFRARED (DVD) TRANSMITTER DISPLAY
ENGINE COOLING FAN
EXCEPT 6 SPEED A/T
HEADLAMP SWITCH INSIDE FOG AIR LAMP TEMPERATURE SWITCH SENSOR
HVAC CONTROL MODULE
HYBRID EXCEPT
HYBRID EXCEPT HYBRID
I/P COMPARTMENT LAMP
I/P MULTI-FUNCTION HORN SWITCH SWITCH
IGNITION COIL/ MODULE 1
IGNITION COIL/ MODULE 2
IGNITION COIL/ MODULE 3
IGNITION COIL/ MODULE 4
IGNITION COIL/ MODULE 6
IGNITION CONTROL MODULE (ICM)
IGNITION LOCK CYLINDER CONTROL SOLENOID
IGNITION SWITCH LAMP
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
MANUAL A/C
NCA WIRE
PANEL MODE ACTUATOR HARNESS BREAKOUT)
PRNDL LAMP
RADIO
REAR SEAT AUDIO (RSA) CONTROL
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT ENGINE COOLING FAN
SPLICE PACK
THEFT DETERRENT MODULE (TDM)
TURN SIGNAL/ MULTI-FUNCTION SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> HEADLAMP SWITCH INSIDE FOG AIR LAMP TEMPERATURE SWITCH SENSOR
