Saturn VUE II (2007-2009) data bus- ign volt data bus- ign volt stop lp sw Wiring diagrams
This page contains all the electrical diagrams for the component. data bus- ign volt data bus- ign volt stop lp sw, in which he is found in the car Saturn VUE II (2007-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram data bus- ign volt data bus- ign volt stop lp sw (1 of 2)
2501 639 2501 5985 17 COMPUTER DATA LINES SYSTEM
3.5L
3.6L ENGINE CONTROL MODULE (ECM) (LEFT FRONT CORNER OF ENGINE COMPT)
ACC VOLT
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION INPUT SHAFT SPEED (ISS) SENSOR
AUTOMATIC TRANSMISSION OUTPUT SHAFT SPEED (OSS) SENSOR
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
COMPUTER
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CRUISE CONTROL SYSTEM PNK WIRE
CYL CTRL ACT SIG
DATA BUS -
DATA BUS- IGN VOLT DATA BUS- IGN VOLT STOP LP SW
DATA LINES
DK BLU WIRE
DK GRN WIRE
ECM/TCM FUSE
GMLAN BUS-
GRN WIRE
GROUND B+
HOT AT ALL TIMES
HOT AT ALL TIMES IGNITION SWITCH
HOT W/ RUN/CRANK RELAY ENERGIZED
I/P FUSE BLOCK
IGN 3 VOLT
INTERNAL MODE SWITCH (IMS)
ISS LOW
ISS/OSS HIGH
LOGIC
OFF
ORG/BLK WIRE
OSS LOW
PNK WIRE
RED WIRE
RED/WHT WIRE
RUN WIRE
SERIAL DATA WAKE UP
STOP LP SPLY VOLT
SYSTEM
TAN WIRE
TAN/BLK WIRE
TAP UP/TAP DOWN
TCM FUSE
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION RANGE SIG A
TRANSMISSION RANGE SIG B
TRANSMISSION RANGE SIG C
TRANSMISSION RANGE SIG P
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> 3.5l vin n, a/t circuit (2 of 2) -> DATA BUS- IGN VOLT DATA BUS- IGN VOLT STOP LP SW
