Saturn VUE II (2007-2009) coolant temperature ind Wiring diagram
This page shows the only wiring diagram for the component.coolant temperature ind, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant temperature ind (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PNK WIRE
ABS IND.
AIR BAG IND
AUDIO FUSE
BCM FUSE 12
BELT IND
BLK WIRE
BRAKE FLUID
BRAKE FLUID LEVEL SWITCH (ON MASTER BRAKE CYLINDER RESERVOIR)
BRAKE IND
BRN/WHT WIRE
CHARGE IND
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE IND
CRUISE IND
DK BLU WIRE
DK GRN WIRE
DOOR AJAR IND
DRIVER INFORMATION CENTER (DIC)
DRL IND
FRONT FOG LAMPS IND
FUEL GAUGE
HIGH BEAM IND
HOT AT ALL TIMES
HOT W/ RUN/CRNK RELAY ENERGIZED
HYBRID FUEL ECONOMY IND
I/P FUSE BLOCK
IGN
ILLUMINATION
INSTRUMENT PANEL CLUSTER (IPC)
LEFT TURN IND
LEVEL SENS
LIFTGATE AJAR IND
LO SPD GMLAN
LOGIC
MALFUNCTION IND
MIL CTRL
ODOMETER
OFF IND CTRL
OIL LEVEL IND
ON IND CTRL
PASS AIR BAG
PASS SEAT
PNK WIRE
PPL
RED/WHT WIRE
RIGHT TURN IND
SEAT BELT IND
SECURITY IND
SERIAL DATA
SPEEDOMETER
SPSS IND
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAN/WHT WIRE
TRACTION OFF IND
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WASHER SIG
WINDSHIELD
WIPER/WASHER SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
Go to component -> Instrument cluster circuit (1 of 2) -> COOLANT TEMPERATURE IND
