Saturn VUE II (2007-2009) center console accessory power outlet rear accessory power outlet Wiring diagram
This page shows the only wiring diagram for the component.center console accessory power outlet rear accessory power outlet, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center console accessory power outlet rear accessory power outlet (1 of 1)
2-3 SHIFT SOLENOID (SS) VALVE
4 SPEED A/T PNK WIRE
6 SPEED A/T
ACC/RAP RELAY
AIR BAG FUSE
AUXILIARY FUSE BLOCK
BLK WIRE
BRN WIRE
CENTER CONSOLE ACCESSORY POWER OUTLET REAR ACCESSORY POWER OUTLET
CIGAR LIGHTER
CLUSTER FUSE
DOOR LOCK PCB RELAY
DOOR UNLOCK PCB RELAY
DRIV P/WIN PASS P/WIN
DRIVER HEATED SEAT SWITCH
DRIVER INFORMATION CENTER (DIC) SWITCH
DRIVER WINDOW SWITCH
DRL RELAY
ECM, TCM
ENGINE TRANSMISSION CONTROL CONTROL MODULE MODULE (ECM) (TCM)
F/DR LCK FUSE
FOG LAMP PCB RELAY 3
FROM
FROM AIR BAG FUSE (I/P FUSE BLOCK) CIGAR (DIAGRAM 2 OF 3) FUSE
FROM CLUSTER FUSE (I/P FUSE BLOCK) ESCM PROVISION (DIAGRAM 3 OF 3) FUSE FUSE
FROM I/P BEC FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 3)
FROM RUN FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 3) HEADLAMP SWITCH
FRONT WASHER PUMP (PCB) RELAY
FUEL SYSTEM CONTROL MODULE (FSCM)
FUSE
FUSE FUSE
HVAC CONTROL MODULE
I/P FUSE BLOCK
INSIDE REARVIEW MIRROR (ISRVM)
INSTRUMENT PANEL CLUSTER (IPC)
ISRVM FUSE
KEY CAP OSRVM FUSE FUSE
LOCK PCB RELAY
NOT USED NOT USED
PASSENGER HEATED SEAT CONTROL MODULE
PNK PNK WIRE
PNK WIRE
RED WIRE
RLYS PCB RELAY
RUN/ CRANK RELAY
TAN WIRE
TO DR LOCK FUSE (I/P FUSE BLOCK) (DIAGRAM 3 OF 3) FUSE FUSE
TO ESCM FUSE (I/P FUSE BLOCK)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WASHER FUSE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> CENTER CONSOLE ACCESSORY POWER OUTLET REAR ACCESSORY POWER OUTLET
