Saturn VUE II (2007-2009) breakout for rear dome light switch harness) Wiring diagram
This page shows the only wiring diagram for the component.breakout for rear dome light switch harness), which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram breakout for rear dome light switch harness) (1 of 1)
BLK WIRE
BOX)
BRAKE FLUID LEVEL SWITCH
BREAKOUT FOR REAR DOME LIGHT SWITCH HARNESS)
CENTER HIGH LEFT MOUNTED REAR STOP MARKER LAMP LAMP (CHMSL)
COURTESY/ READING LAMPS
DOME LAMP
DOOR HARNESS)
GARAGE DOOR OPENER (GDO)
GENERATOR BATTERY ASSEMBLY
LEFT BACK-UP LAMP
LEFT REAR DOOR LATCH LEFT REAR DOOR JAMB SWITCH
LEFT REAR LAMPS
LEFT REAR TAIL/ STOP LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT REAR WINDOW SWITCH
LEFT SUNSHADE
LICENSE LAMP
LIFTGATE AJAR SWITCH
LIFTGATE LATCH ASSEMBLY
LIFTGATE LOCK ACTUATOR
NCA WIRE
ONSTAR BUTTON RIGHT ASSEMBLY SUNSHADE
PASSENGER DOOR HARNESS)
REAR ACCESSORY POWER OUTLET
REAR COMPARTMENT COURTESY AUDIO LAMP AMPLIFIER
REAR COMPARTMENT COURTESY LAMP
REAR FUEL DIFFERENTIAL PUMP CLUTCH FLOW CONTROL CONTROL MODULE MODULE
REAR LIFTGATE WINDOW RELEASE DEFOGGER SWITCH GRID
REAR WINDOW WIPER CONTROL MODULE
RIGHT BACK-UP LAMP
RIGHT REAR DOOR LATCH RIGHT REAR DOOR JAMB SWITCH
RIGHT REAR LAMPS RIGHT TAIL/ STOP LAMP
RIGHT REAR MARKER LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT REAR WINDOW SWITCH
W/ C MODEL REGULAR
WINDSHIELD INSIDE REARVIEW OUTSIDE MIRROR MOISTURE (ISRVM) SENSOR
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (4 of 4) -> BREAKOUT FOR REAR DOME LIGHT SWITCH HARNESS)
