Saturn VUE II (2007-2009) awd fuse 32 Wiring diagram
This page shows the only wiring diagram for the component.awd fuse 32, which is found in the car Saturn VUE II (2007-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram awd fuse 32 (1 of 1)
AWD FUSE 32
BLK WIRE
COIL TEMP SENS SIG LOCK SOLENOID CTRL LOW REFERENCE DIAGNOSTIC ENABLE
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL CLUTCH PUMP ACTUATOR CHECK VALVE
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
GMLAN DATA BUS- GMLAN DATA BUS+
GROUND
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LT BLU WIRE
ORG/ WIRE
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
RED/WHT WIRE
SERIAL DATA
SERIAL DATA B+
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> Rear differential lock circuit -> AWD FUSE 32
