Saturn VUE II (2007-2009) accessory voltage Wiring diagrams
This page contains all the electrical diagrams for the component. accessory voltage, in which he is found in the car Saturn VUE II (2007-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram accessory voltage (1 of 2)
18 14 OUTSIDE MOISTURE SIG 1 OUTSIDE MOISTURE SIG 2
ACCESSORY VOLTAGE
BAT POS VOLT
BCM FUSE 12
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
GROUND MOISTURE SENSOR (BEHIND INSIDE REARVIEW MIRROR) LOGIC
HOT AT ALL TIMES
LT GRN WIRE
OUTSIDE ACCESS MOISTURE VOLT SENSOR SIGNAL
OUTSIDE MOISTURE SENSOR SIGNAL
RED WIRE
RED/WHT WIRE
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WINDSHIELD OUSIDE
Go to component -> Moisture sensor circuit -> ACCESSORY VOLTAGE
Wiring diagram accessory voltage (2 of 2)
ACCESSORY VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
DK GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
LIFTGATE AJAR SW SIG
LIFTGATE AJAR SWITCH
LIFTGATE LATCH ASSEMBLY
LOGIC
PNK/BLK WIRE
REAR WINDOW WIPER CONTROL MODULE
REAR WINDOW WIPER SW SIG
REAR WINDSHIELD WASHER FLUID PUMP
REAR WINDSHIELD WIPER/WASHER SWITCH
REAR WPR FUSE
RED WIRE
RED/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Rear wiper/washer circuit -> ACCESSORY VOLTAGE
