Saturn VUE I (2001-2007) underhood fuse block (left side of engine Wiring diagram
This page shows the only wiring diagram for the component.underhood fuse block (left side of engine, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram underhood fuse block (left side of engine (1 of 1)
A/T
AUTOMATIC TRANSMISSION
BATTERY
BLK WIRE
CLUTCH
FUSIBLE LINK
GENERATOR
IGNITION FUSE
IGNITION SWITCH
LOCK OFF
M/T
OF AUTOMATIC TRANSMISSION)
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RUN WIRE
STARTER
SWITCH (ON CLUTCH PEDAL BRACKET)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
YEL WIRE
Go to component -> 2.2l vin d, starting circuit -> UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE
