Saturn VUE I (2001-2007) stp lmp sw signal Wiring diagram
This page shows the only wiring diagram for the component.stp lmp sw signal, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stp lmp sw signal (1 of 1)
BLK WIRE
BRAKE FUSE
BRAKE SW SIG
CRUISE CONTROL SWITCH
CRUISE FUSE
CRUISE INDICATOR
CRUISE ON/OFF SW SIG
CRUISE SET/COAST SW SIG
CRUISE/ BRAKE SWITCH (ON BRAKE PEDAL BRACKET)
DK BLU WIRE
GROUNDED TO STEERING WHEEL
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
LT BLU WIRE
NCA WIRE
ON/OFF SWITCH
ORG/ WIRE
PNK WIRE
PPL
RESUME/ ACCEL SWITCH
RESUME/ACCEL SW SIG
SET/COAST SWITCH
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
STP LMP SW SIGNAL
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> 3.5l vin 4, cruise control circuit -> STP LMP SW SIGNAL
