Saturn VUE I (2001-2007) stp lmp sw input wiring diagram
This page shows the only wiring diagram for the component.stp lmp sw input, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stp lmp sw input wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BRAKE FUSE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
CRUISE FUSE
CRUISE ON
CRUISE ON/OFF
CRUISE ON/OFF SWITCH
CRUISE SET/COAST
CRUISE SET/RESUME SWITCH
CRUISE/ BRAKE SWITCH (ON BRAKE PEDAL BRACKET)
DK BLU WIRE
ENGINE CONTROL MODULE (ECM) (ON INTAKE MANIFOLD, UNDER IGNITION COIL HOUSING)
GROUNDED TO STEERING WHEEL
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
LT BLU WIRE
NCA WIRE
ON OFF OFF
ORG/ WIRE
PNK WIRE
PPL
PPL BRAKE SW SIG
RESUME/ ACCEL
RESUME/ACCEL
SET/ COAST
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
STP LMP SW INPUT
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> 2.2l vin d, cruise control circuit -> STP LMP SW INPUT
