Saturn VUE I (2001-2007) primary fuel pump, sender assembly Wiring diagram
This page shows the only wiring diagram for the component.primary fuel pump, sender assembly, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram primary fuel pump, sender assembly (1 of 1)
10 29 2.2L 3.5L
2.2L
2.2L, 3.5L
3.5L
ABS IND.
AIR BAG IND
BATTERY IND
BCM/ CLUSTER FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER
BRAKE CYLINDER RESERVOIR)
BRAKE FLUID LEVEL SWITCH (ON MASTER
BRAKE IND
CAN HIGH
CAN LOW
CHANGE OIL SOON IND
COMPUTER DATA LINES SYSTEM
COOLANT TEMP GAUGE
COOLANT TEMP IND
DK BLU WIRE
DRL IND
ENGINE CONTROLS SYSTEM
ENGINE OIL PRESSURE SWITCH
FLOOR CONSOLE)
FUEL GAUGE
FUEL LEVEL SENSOR
GRY WIRE
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
IGN 1 FUSE
ILLUMINATION (4 BULBS)
INSTRUMENT PANEL CLUSTER (IPC)
KM/MILES 000000 TRIP
LCD DISPLAY
LEFT TURN IND
LIFTGATE AJAR IND
LOGIC
LOW COOLANT IND
LOW FUEL IND
LOW REF
LOW TRACTION IND
LT BLU WIRE
MALFUNCTION IND LAMP
ODOMETER BACKLIGHT
OIL PRESSURE IND
ORG/ WIRE
PARK BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER)
PARK BRAKE SWITCH SIG
PNK WIRE
PPL
PPL BRAKE FLUID LEVEL SW SIG
PPL CLASS 2 SERIAL DATA
PPL FUEL LEVEL SENSOR
PPL UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
PRIMARY FUEL PUMP, SENDER ASSEMBLY
REDUCED POWER IND
RIGHT TURN IND
SEAT BELT IND
SECONDARY FUEL PUMP, SENDER ASSEMBLY
SECURITY IND
SECURITY LED CONTROL
SEN SIG
SERIAL DATA GND GND
SERVICE IND
SHIFT UP IND
SPEEDOMETER
SPLICE PACK
SW SIG
TACHOMETER
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRACTION CNTRL OFF INDICATOR
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Instrument cluster circuit -> PRIMARY FUEL PUMP, SENDER ASSEMBLY
