Saturn VUE I (2001-2007) pnk ignition 1 volt park lamp input Wiring diagram

BATTERY BATTERY GROUND BCM IGN 1 FUSE BCM/ CLUSTER FUSE BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE) BRN WIRE CHIME CLASS 2 (SDM) (IGN) SEAT BELT IND COMPUTER DATA LINES SYSTEM DATA CLASS 2 DATA CLASS 2 LEFT SEAT BELT SW LOW REFERENCE GRN WIRE GRY WIRE GRY/BLK WIRE HDLP OFF PARK HEADLAMP SWITCH HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK (BEHIND CENTER OF DASH) IGNITION SWITCH (KEY MINDER) DRIVER DOOR JAMB SWITCH INSTRUMENT PANEL CLUSTER (IPC) INT LIGHTS FUSE KEY IN IGN SW SIG PARK BRAKE INPUT LF DOOR AJAR LOGIC SERIAL DATA SERIAL DATA LT BLU WIRE LT GRN WIRE ORG/ WIRE PARK BRAKE SWITCH (CLOSED W/ PARK BRAKE APPLIED) (AT BASE OF PARK BRAKE LEVER) PARK LP FUSE PNK IGNITION 1 VOLT PARK LAMP INPUT WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL DATA CLASS 2 CAN LOW CAN HIGH DATA CLASS 2 DATA CLASS 2 PPL PPL RED WIRE TAN WIRE TAN/WHT WIRE WHT WIRE
