Saturn VUE I (2001-2007) low speed cooling fan rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.low speed cooling fan rly ctrl, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low speed cooling fan rly ctrl (1 of 1)
56 40 ECT SIG LOW REF
BLK WIRE
BLU WIRE
COOL 1 FUSE
COOL 2 FUSE
COOL FAN 1 RELAY
COOL FAN 2 RELAY
DK BLU WIRE
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (AT REAR OF ENGINE)
GRN/YEL WIRE
GRY WIRE
HIGH SPEED COOLING FAN RLY CTRL
HOT AT ALL TIMES
LEFT COOLING FAN (BEHIND LEFT SIDE OF RADIATOR)
LOW SPEED COOLING FAN RLY CTRL
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM)
RIGHT COOLING FAN (BEHIND RIGHT SIDE OF RADIATOR)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> 3.5l vin 4, cooling fan circuit -> LOW SPEED COOLING FAN RLY CTRL
