Saturn VUE I (2001-2007) left front park/turn signal lamp right front marker lamp Wiring diagram
This page shows the only wiring diagram for the component.left front park/turn signal lamp right front marker lamp, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front park/turn signal lamp right front marker lamp (1 of 1)
2.2L
3.5L
A/C COMPRESSOR CLUTCH
A/C DIODE
A/T
BANK 2 SENSOR 1 SHIELD
BANK 2 SENSOR 2 SHIELD
BATTERY
BLK WIRE
BLK/WHT WIRE
BRN/YEL WIRE
COOLING FAN RELAY
DAYTIME RUNNING LAMP (DRL) RESISTOR
ENGINE CONTROL MODULE (ECM)
EXHAUST GAS RECEIVER (EGR) VALVE IGNITION CONTROL MODULE (ICM) 1
FUEL PUMP RELAY
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR CRANK SHAFT POSITION (CKP) SENSOR
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR
HORN
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
IGNITION CONTROL MODULE
IGNITION CONTROL MODULE (ICM) 5
IGNITION CONTROL MODULE (ICM) 6
KNOCK SENSOR SHIELD BANK 1 SENSOR 1 SHIELD BANK 1 SENSOR 2 SHIELD
LEFT FOG LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP RIGHT FRONT MARKER LAMP
M/T
POWER STEERING CONTROL MODULE (PSCM)
POWER WINDOW RELAY
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FOG LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
SPLICE PACK
TRANSMISSION CONTROL MODULE (TCM)
VEHICLE SPEED SENSOR
WIPER SYSTEM RELAY
Go to component -> Ground distribution circuit (1 of 3) -> LEFT FRONT PARK/TURN SIGNAL LAMP RIGHT FRONT MARKER LAMP
