Saturn VUE I (2001-2007) hot in run on start Wiring diagram
This page shows the only wiring diagram for the component.hot in run on start, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in run on start (1 of 1)
2.2L, 3.5L
A/C CLUTCH FUSE
A/T
A/T M/T
ACCESSORY VOLTAGE
AMBIENT AIR TEMPERATURE SENSOR (BEHIND FRONT GRILLE)
AMBIENT LIGHT SENSOR
AUTOMATIC DAY/NIGHT MIRROR ELEMENT
AUTOMATIC TRANSMISSION
BACKUP FUSE
BACKUP LAMP RELAY
BACKUP SWITCH (AT LEFT SIDE OF TRANSM- ISSION)
BLK WIRE
BRN/WHT WIRE
DK GRN/WHT WIRE
ELECTRONIC TRANSMISSION 4 SPEED TRANSMISSION
GREEN LED
GREEN LED SIG
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN RUN ON START
I/P FUSE BLOCK
IGN
INSIDE REARVIEW MIRROR
KEY PAD POWER
KEY SIG
KEY SIGNAL
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
M/T
MAGNETIC FIELD SENSOR
MESS REQ LOW REF
MIRROR DISPLAY
MIRROR SIG
OF AUTOMATIC TRANSMISSION)
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
RADIO (BEHIND FUSE CENTER OF DASH)
RED LED SIG WIRE
RED LED WIRE
REV
REVERSE SWITCH
SENS SIG
SPLICE PACK
TEMP
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (UNDER LEFT SIDE OF DASH)
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit -> HOT IN RUN ON START
