Saturn VUE I (2001-2007) hot at all times Wiring diagrams

A/T SHIFT LOCK SOLENOID (IN FRONT CENTER CONSOLE, AT BASE OF SHIFTER ASSEMBLY) BACKUP FUSE BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE) BTSI CONTROL BRAKE FUSE BRAKE LAMPS CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK (BEHIND CENTER OF DASH) IGN 1 FUSE LT BLU WIRE ORG/ WIRE PARK/ NEUTRAL POSITION SWITCH PNK WIRE STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) TAN WIRE TAN/WHT WIRE TR C TR B TR-A TR-P UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE

A/T SHIFT LOCK SOLENOID (IN FRONT CENTER CONSOLE, AT BASE OF SHIFTER ASSEMBLY) BLK WIRE BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE) BTSI CONTROL BRAKE FUSE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK (BEHIND CENTER OF DASH) IGN 1 FUSE LT BLU WIRE ORG/ WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) CAN LOW STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET) STOP LAMP SWITCH INPUT TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE

12 2 1 8 MUTE SIG R AUDIO SIG L AUDIO SIG DRAIN WIRE 8 9 INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM ANTENNA BARE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE COAX COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FRONT DOOR) GM LAN SERIAL DATA ACCESSORY VOLT GROUND GROUND BATTERY GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN I/P FUSE BLOCK (BEHIND CENTER OF DASH) IP LAMP SUPPLY VOLT PARK LAMP SUPPLY VOLT LEFT FRONT SPEAKER LEFT FRONT SPEAKER (TWEETER) LEFT REAR SPEAKER LT BLU WIRE LT GRN WIRE MUTE SIGNAL GM LAN SERIAL DATA NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK/BLK WIRE R AUDIO SIG (+) L AUDIO SIGNAL (+) AUDIO COMMON R AUDIO SIGNAL L AUDIO SIGNAL RADIO RADIO ANTENNA RADIO FUSE RADIO IGN FUSE RIGHT FRONT SPEAKER RIGHT FRONT SPEAKER (TWEETER) RIGHT REAR SPEAKER SATELLITE RADIO CIRCUIT SPLICE PACK TAN WIRE W/ 6 SPEAKERS YEL WIRE YEL/BLK WIRE

BLK WIRE DK BLU WIRE DK GRN WIRE DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT HORIZONTAL MOTOR (UNDER DRIVER SEAT) DRIVER SEAT RECLINE MOTOR (UNDER DRIVER SEAT) DRIVER SEAT VERTICAL MOTOR (UNDER DRIVER SEAT) FRONT VER UP FRONT VER DOWN HOR FWD HOR RWD HOT AT ALL TIMES LT BLU WIRE ORG/ WIRE PWR SEAT CIRCUIT BREAKER FUSE REAR VER DOWN REAR VER UP RED WIRE SPLICE PACK UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) YEL WIRE

1 2 3 4 GROUND HI/LOW SIG SWITCH SIG BATTERY PNK WIRE BLK WIRE BRN WIRE DRIVER HEATED SEAT MODULE (UNDER LEFT FRONT SEAT) DRIVER HEATED SEAT SWITCH FRONT PASSENGER HEATED SEAT MODULE (UNDER RIGHT FRONT SEAT) FRONT PASSENGER HEATED SEAT SWITCH GRY WIRE HEATED SEAT BACK HEATED SEAT CUSHION HEATED SEATS HI LO HOT AT ALL TIMES HOT IN RUN HEATED SEATS FUSE I/P FUSE BLOCK (BEHIND CENTER OF DASH) LOW REF TEMP SIG LT BLU WIRE LT BLU/BLK WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE RED WIRE SPLICE PACK UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)

BLK WIRE DOWN DRIVER OUTSIDE REARVIEW MIRROR PASSENGER OUTSIDE REARVIEW MIRROR HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND CENTER OF DASH) LEFT LEFT RIGHT RIGHT OFF OFF LOCK/MIRROR FUSE LT GRN WIRE NCA WIRE ORG/ WIRE OUTSIDE REARVIEW MIRROR SWITCH PPL/WHT WIRE RED/WHT WIRE RIGHT RIGHT/ LEFT MOTOR SPLICE PACK UP LEFT UP/ DOWN MOTOR UP/ DOWN MOTOR LEFT/ RIGHT MOTOR WHT WIRE YEL WIRE

1 2 3 4 5 6 7 8 LOW REF 2074 128 100 EXPRESS CLOSE IN LOW REF SLIDE OPEN IN VENT OPEN IN SOFT STOP SIG BATTERY BLK WIRE BRN WIRE CLOSE DK BLU WIRE DK GRN WIRE GROUND HOT AT ALL TIMES HOT IN ACC OR RUN LIMIT SWITCH LOGIC LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PWR WDW CIRCUIT BREAKER PWR WDW RELAY RED WIRE SLIDE SOLID STATE SPLICE PACK SUNROOF CONTROL MODULE (AT LEFT FRONT OF SUNROOF MODULE) SUNROOF FUSE SUNROOF MOTOR (RIGHT FRONT OF SUNROOF MODULE ASSEMBLY) SUNROOF SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) VENT OPEN YEL WIRE

BCM FUSE BLK WIRE BRN WIRE DK BLU WIRE DK GRN WIRE DOWN DRIVER WINDOW MOTOR (IN LEFT FRONT DOOR) DRIVER WINDOW SWITCH EXPRESS LOGIC FRONT PASSENGER WINDOW MOTOR (IN RIGHT FRONT DOOR) FRONT PASSENGER WINDOW SWITCH HOT AT ALL TIMES HOT IN ACC OR RUN I/P FUSE BLOCK (BEHIND CENTER OF DASH) LEFT FRONT LEFT REAR LEFT REAR WINDOW MOTOR (IN LEFT REAR DOOR) LEFT REAR WINDOW SWITCH LT GRN WIRE PPL PWR WDW CIRCUIT BREAKER PWR WDW RELAY REAR WINDOW LOCKOUT SWITCH RIGHT FRONT RIGHT REAR RIGHT REAR WINDOW MOTOR (IN RIGHT REAR DOOR) RIGHT REAR WINDOW SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) UP DN UP DOWN YEL WIRE

12 2 1 8 MUTE SIG R AUDIO SIG L AUDIO SIG DRAIN WIRE AMPLIFIER CONTROL IP LAMP SUPPLY VOLT PARK LAMP SUPPLY VOLT ANTENNA BARE BARE BARE BATTERY BATTERY BLK/WHT WIRE BRN WIRE BRN/WHT WIRE COAX COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE GMLAN SERIAL DATA ACCESSORY VOLT GROUND GRY WIRE HOT AT ALL TIMES HOT IN ACC OR RUN I/P FUSE BLOCK (BEHIND CENTER OF DASH) INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM LT BLU WIRE LT GRN WIRE MUTE SIG GMLAN SERIAL DATA NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PREM AUDIO FUSE R AUDIO SIG (+) L AUDIO SIGNAL (+) AUDIO COMMON R AUDIO SIG L AUDIO SIG RADIO RADIO ANTENNA RADIO FUSE RADIO IGN FUSE SATELLITE RADIO CIRCUIT SPLICE PACK TAN WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BARE BATTERY BLK/WHT WIRE BRN/WHT WIRE COAX ANT IN (SAT) COAX ANT IN (TERR) DIGITAL RADIO ANTENNA DIGITAL RADIO RECEIVER DK GRN WIRE DK GRN/WHT WIRE EARLY PRODUCTION GROUND AUD COMMON DRAIN WIRE HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND CENTER OF DASH) L AUDIO (+) R AUDIO (+) L AUDIO SIG (+) R AUDIO SIG (+) SERIAL DATA GROUND AUDIO COMMON LATE PRODUCTION LOCK/ MIRROR FUSE NCA WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM RADIO RADIO FUSE SERIAL DATA
