Saturn VUE I (2001-2007) ground aud common drain wire Wiring diagram
This page shows the only wiring diagram for the component.ground aud common drain wire, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground aud common drain wire (1 of 1)
BARE
BATTERY
BLK/WHT WIRE
BRN/WHT WIRE
COAX ANT IN (SAT)
COAX ANT IN (TERR)
DIGITAL RADIO ANTENNA
DIGITAL RADIO RECEIVER
DK GRN WIRE
DK GRN/WHT WIRE
EARLY PRODUCTION
GROUND AUD COMMON DRAIN WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
L AUDIO (+) R AUDIO (+)
L AUDIO SIG (+) R AUDIO SIG (+) SERIAL DATA GROUND AUDIO COMMON
LATE PRODUCTION
LOCK/ MIRROR FUSE
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RADIO
RADIO FUSE
SERIAL DATA
Go to component -> Satellite radio circuit -> GROUND AUD COMMON DRAIN WIRE
