Saturn VUE I (2001-2007) front ver up front ver down Wiring diagram
This page shows the only wiring diagram for the component.front ver up front ver down, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front ver up front ver down (1 of 1)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT HORIZONTAL MOTOR (UNDER DRIVER SEAT)
DRIVER SEAT RECLINE MOTOR (UNDER DRIVER SEAT)
DRIVER SEAT VERTICAL MOTOR (UNDER DRIVER SEAT)
FRONT VER UP FRONT VER DOWN
HOR FWD
HOR RWD
HOT AT ALL TIMES
LT BLU WIRE
ORG/ WIRE
PWR SEAT CIRCUIT BREAKER FUSE
REAR VER DOWN
REAR VER UP
RED WIRE
SPLICE PACK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Driver seat circuit -> FRONT VER UP FRONT VER DOWN
