Saturn VUE I (2001-2007) front driver heated seat switch passenger heated seat switch Wiring diagram
This page shows the only wiring diagram for the component.front driver heated seat switch passenger heated seat switch, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front driver heated seat switch passenger heated seat switch (1 of 1)
2.2L
2.2L, W/
AUXILIARY POWER OUTLET
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
C-M
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DATA LINK CONNECTOR (DLC)
DOOR LOCK RELAY
DRIVER DOOR JAMB SWITCH
DRIVER DOOR UNLOCK RELAY
DRIVER HEATED SEAT CONTROL MODULE
DRIVER SEAT ADJUSTER SWITCH
DRIVER WINDOW SWITCH CIGAR LIGHTER
FOG LAMP SWITCH
FRONT DRIVER HEATED SEAT SWITCH PASSENGER HEATED SEAT SWITCH
FRONT PASSENGER DOOR JAMB SWITCH
FRONT PASSENGER HEATED SEAT CONTROL MODULE
HAZARD SWITCH
HEAD- LAMP SWITCH
HORN SWITCH
HVAC BLOWER RELAY
HVAC CONTROL MODULE
I/P FUSE BLOCK
IGNITION SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER
LEFT LICENSE LAMP
LEFT REAR DOOR JAMB SWITCH RIGHT REAR DOOR JAMB SWITCH
LIFTGATE LATCH
NCA WIRE
NOT USED
OUTSIDE REAR VIEW MIRROR SWITCH
PASS- ENGER DOOR UNLOCK RELAY
PRNDL LAMP
RADIO
REAR WIPER MOTOR
RIGHT LICENSE LAMP
SPLICE PACK
TRANSMISSION CONTROL MODULE (TCM)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/O REMOTE ENTRY LOCK CONTROL
WHT WIRE
WIND- SHIELD WIPER MOTOR FRONT PASSENGER WINDOW SWITCH
WINDSHIELD WIPER/WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 3) -> FRONT DRIVER HEATED SEAT SWITCH PASSENGER HEATED SEAT SWITCH
