Saturn VUE I (2001-2007) field duty cycle signal Wiring diagram
This page shows the only wiring diagram for the component.field duty cycle signal, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram field duty cycle signal (1 of 1)
3.5L, 2.2L
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
CAN HIGH
CAN LOW
CHARGE INDICATOR
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM)
FIELD DUTY CYCLE SIGNAL
FUSIBLE LINK
GEN OUT
GENERATOR
HOT IN RUN OR START
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
IGN 1 FUSE
IGN CLASS 2 (BCM) SERIAL DATA CLASS 2
INSTRUMENT PANEL CLUSTER
LOGIC
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL SERIAL DATA CLASS 2
RED WIRE
STARTER
TAN WIRE
TAN/WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Charging circuit -> FIELD DUTY CYCLE SIGNAL
