Saturn VUE I (2001-2007) exterior lights, cruise control systems Wiring diagram
This page shows the only wiring diagram for the component.exterior lights, cruise control systems, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior lights, cruise control systems (1 of 1)
AUTOMATIC TRANSMISSION
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE FUSE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUTCH PRESSURE CONTROL SOLENOID VALVES (IN AUTOMATIC TRANSMISSION)
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH)
DK BLU WIRE
DK BLU/BLK WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM/TCM FUSE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
ETC CTRL
ETC FUSE
ETC SIG
EXTERIOR LIGHTS, CRUISE CONTROL SYSTEMS
GND GND ETC CTRL ETC SIG TFT SEN SIG ECT SEN SIG
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRND
HOT AT ALL TIMES
HOT IN RUN OR START
IGN 1
LT BLU WIRE
MINHIBIT
ORG/ WIRE
POWERTRAIN CONTROL MODULE (IN ENGINE COMPT, MOUNTED NEAR RIGHT STRUT TOWER)
PRESSURE SWITCH (AT REAR OF AUTOMATIC TRANSMISSION)
PWR TRAIN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SHIFT SOLENOID VALVES
SPLICE PACK
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TAC MODULE CIRCUIT)
TAN WIRE
TAN/WHT WIRE
TORQUE CONVERTER CLUTCH ENABLE SOLENOID VALVE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> 3.5l vin 4, a/t circuit (1 of 2) -> EXTERIOR LIGHTS, CRUISE CONTROL SYSTEMS
