Saturn VUE I (2001-2007) battery ground Wiring diagram
This page shows the only wiring diagram for the component.battery ground, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery ground (1 of 1)
BATTERY GROUND
BLK WIRE
CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA IGNITION
EPS FUSE
EPS INLINE FUSE HOLDER (IN ENGINE COMPT, ON LEFT STRUT TOWER, NEAR A/C LINE)
EPS MOTOR
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
LOGIC
PNK WIRE
POWER STEERING CONTROL MODULE (PSCM)
RED WIRE
RIGHT ASSIST MTR CTRL LEFT ASSIST MTR CTRL
STEERING COLUMN)
STEERING SHAFT TORQUE SENSOR
Go to component -> Electronic power steering circuit -> BATTERY GROUND
