Saturn VUE I (2001-2007) a/c request signal defogger indicator Wiring diagram
This page shows the only wiring diagram for the component.a/c request signal defogger indicator, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c request signal defogger indicator (1 of 1)
A/C REQUEST
A/C REQUEST SIGNAL DEFOGGER INDICATOR
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
GROUND
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
HVAC FUSE
HVAC MODULE (AT CENTER OF DASH)
I/P FUSE BLOCK (BEHIND CENTER OF DASH)
IGNITION 1 VOLTAGE
LOGIC
LT BLU WIRE
LT GRN WIRE
PANEL)
PPL
REAR DEFOG FUSE
REAR DEFOG RELAY
REAR DEFOGGER GRID
REAR DEFOGGER SWITCH
RLY CTRL
SPLICE PACK
SW INPUT
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
Go to component -> Defoggers circuit -> A/C REQUEST SIGNAL DEFOGGER INDICATOR
