Saturn VUE I (2001-2007) 56 3 22 2 11 10 clu rly ctrl low reference Wiring diagram

56 3 22 2 11 10 CLU RLY CTRL LOW REFERENCE A/C CLUTCH FUSE A/C CLUTCH RELAY A/C COMPRESSOR CLUTCH (AT LOWER LEFT FRONT OF ENGINE) A/C DIODE A/C PRESS SENS CAN HIGH CAN LOW A/C REFRIGERANT PRESSURE SENSOR (IN A/C HIGH SIDE PRESSURE LINE) A/C REQUEST EVAP TEMP SENS BLK WIRE BODY CONTROL MODULE (BCM) (BELOW FRONT OF CENTER FLOOR CONSOLE) CAN-LOW CAN-HIGH COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE EVAPORATOR TEMPERATURE SENSOR (IN ENGINE COMPARTMENT, ON EXPANSION VALVE BLOCK) GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START HVAC CONTROL MODULE (AT CENTER OF DASH) LOGIC A/C REQ SIG LT GRN WIRE PPL PPL EVAP TEMP SENS RED/BLK WIRE SPLICE PACK TAN WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE
