Saturn VUE I (2001-2007) 38 41 low ret ect sig Wiring diagram
This page shows the only wiring diagram for the component.38 41 low ret ect sig, which is found in the car Saturn VUE I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 38 41 low ret ect sig (1 of 1)
13 57 FAN 1 RLY CTRL FAN 2 RLY CTRL
38 41 LOW RET ECT SIG
BLK WIRE
COOL FAN HIGH FUSE
COOL FAN HIGH RELAY
COOL FAN LOW RELAY
COOL LOW FUSE
COOLING FAN MOTOR (BEHIND RADIATOR)
COOLING FAN RESISTOR (AT LEFT FRONT OF ENGINE COMPT)
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (ECM) (ON INTAKE MANIFOLD, UNDER IGNITION COIL HOUSING)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON THERMOSTAT HOUSING)
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
SPLICE PACK
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> 2.2l vin d, cooling fan circuit -> 38 41 LOW RET ECT SIG
