Instrument cluster circuit for Saturn SL II (1996-2002)

ABS IND. AIR BAG IND BCM FUSE BLK WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH) BRAKE FLUID LEVEL SENS BRAKE IND CHARGE IND COOLANT LEVEL IND COOLANT TEMP GAUGE DK BLU/WHT WIRE DRL IND FUEL GAUGE GROUND GRY WIRE HATCH AJAR IND HIGH BEAM IND HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK (IPFB) (BEHIND CENTER OF DASH) I/P SPLICE PACK 2 IGN 1 FUSE ILLUMINATION (4 BULBS) INSTRUMENT CLUSTER LEFT TURN IND LOW BRAKE FLUID SWITCH (IN MASTER CYLINDER) LOW FUEL IND LOW WASHER FLUID IND LT BLU WIRE LT BLU/WHT WIRE MALFUNCTION IND LAMP OIL LIFE IND OIL PRESSURE IND ORG/ WIRE PARK BRAKE SW SIGNAL PARK BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER) PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (BETWEEN BATTERY, POWER BRAKE BOOSTER) PPL RIGHT TURN IND SEAT BELT IND SECURITY IND SECURITY LED DRIVER SENSING, DIAGNOSTIC MODULE (SDM) (UNDER CENTER FLOOR CONSOLE) SERIAL DATA SERIAL DATA CLASS 2 SERVICE VEHICLE IND SPEEDOMETER TACHOMETER TAN/WHT WIRE TRACTION ACTIVE IND UPSHIFT IND YEL WIRE
