Wiper/washer circuit for Saturn Sky I (2006-2009)
Wiper/washer circuit
BLK WIRE
BODY CONTROL MODULE (BCM) (RIGHT OF HVAC MODULE)
BODY CONTROL MODULE (BCM) LOGIC (RIGHT OF HVAC MODULE)
DELAY SWITCH
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LOW HIGH
LOW INT
LOW OFF INT
LT GRN WIRE
MIST
MIST OFF
ORG/ WIRE
PNK WIRE
PPL
UNDERHOOD FUSE BLOCK
WASHER SWITCH
WINDSHIELD WASHER PUMP CONTROL
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER RELAY CONTROL
WINDSHIELD WIPER SWITCH LOW PULSE SIG
WINDSHIELD WIPER/WASHER SWITCH
WIPER SWITCH
WPR DIODE 58
WPR FUSE 15
WPR FUSE 59
WPR LOW/ HIGH RELAY 52
WPR ON/OFF RELAY 70
YEL WIRE
