Charging circuit for Saturn Sky I (2006-2009)
Charging circuit
2.4L 2.0L
BATTERY
BATTERY SEVER ACTIVE CHARGING SYSTEM ACTIVE STARTING DISABLED
BLK WIRE
BODY CONTROL MODULE (BCM) (RIGHT OF HVAC MODULE)
CHARGE IND
COMPUTER DATA LINES SYSTEM
DK GRN/BLK WIRE
DRIVER INFORMATION CENTER (DIC)
FUSIBLE LINK (10 GA-
GENERATOR
GENERATOR FIELD DUTY CYCLE SIGNAL
GENERATOR TURN ON SIGNAL
GMLAN
GROUND
GRY WIRE
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT IN ON OR START
HVAC/IP IGN FUSE
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW SPPED GMLAN SERIAL DATA
MESSAGE REQUEST
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
STARTER
TAN WIRE
TAN/BLK WIRE
