Satellite radio circuit for Saturn Sky I (2006-2009)
Satellite radio circuit
1 2 9 L AUDIO SIG (+) R AUDIO SIG (+) AUDIO COMMON
ANTENNA SIG
BATTERY
BLK WIRE
BLK/WHT WIRE
BRN/WHT WIRE
COAX
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
DIGITAL RADIO RECEIVER
DK GRN WIRE
DK GRN/WHT WIRE
GROUND AUD COMMON DRAIN
HOT AT ALL TIMES
L AUD SIG + R AUD SIG +
NCA WIRE
RADIO
RED WIRE
RED/WHT WIRE
S BAND ONSTAR/RKE FUSE 56
SATELLITE ANTENNA
SERIAL DATA
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (IN RIGHT REAR CORNER OF ENGINE COMPT)
WHT WIRE
