2.0l vin m turbo, cooling fan circuit for Saturn Sky I (2006-2009)
2.0l vin m turbo, cooling fan circuit
2 20 38 DATA BUS (+) DATA BUS (-) GMLAN SERIAL DATA
44 82 LOW REF ECT SENS SIG
46 55 42 CLG FAN SPD CTRL DATA BUS (-) DATA BUS (+)
BLK WIRE
BODY CONTROL MODULE (BCM) (RIGHT OF HVAC MODULE)
COMPUTER DATA LINES SYSTEM
COOLING FAN SPEED CONTROL
DK GRN/BLK WIRE
ENG COOL FAN FUSE 1
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT REAR CORNER OF ENGINE BLOCK)
ENGINE COOLING FAN (AT FRONT OF ENGINE COMPT, BEHIND RADIATOR)
GMLAN SERIAL DATA
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LT GRN/BLK WIRE
MESSAGE CENTER LOW COOLANT COOLING MODE ON
MESSAGE REQUEST
RED WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (IN RIGHT REAR CORNER OF ENGINE COMPT)
WHT WIRE
YEL WIRE
