Saturn Sky I (2006-2009) trs sig a trs sig b hi spd ser data- Wiring diagram
This page shows the only wiring diagram for the component.trs sig a trs sig b hi spd ser data-, which is found in the car Saturn Sky I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trs sig a trs sig b hi spd ser data- (1 of 1)
2.0L A/T
2.0L M/T
A/T M/T
APPROXIMATELY 13.5 CM
AUTOMATIC TRANSMISSION
BACK UP LAMP
BACK-UP LAMP RLY CTRL
BCK-UP LAMP
BCK-UP LAMP RELAY 28
BLK WIRE
BLK/WHT WIRE
BREAKOUT)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
FUSE 31
FUSE 46
GRN WIRE
HI SPD SER DATA +
HOT AT ALL TIMES
HOT IN RUN OR START
INTERNAL MODE SWITCH (IMS)
LEFT BACK-UP LAMP
LOGIC
LT GRN WIRE
LT PNK WIRE
NCA WIRE
RED WIRE
RIGHT BACK-UP LAMP
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL MODULE (TCM) (NEAR BRAKE MASTER CYLINDER)
TRS SIG A TRS SIG B HI SPD SER DATA-
UNDERHOOD FUSE BLOCK (IN RIGHT REAR CORNER OF ENGINE COMPT)
YEL WIRE
Go to component -> Back-up lamps circuit -> TRS SIG A TRS SIG B HI SPD SER DATA-
