Saturn Sky I (2006-2009) ign 1 voltage mass, pos sig airbag on sig ground airbag off sig pnk Wiring diagram
This page shows the only wiring diagram for the component.ign 1 voltage mass, pos sig airbag on sig ground airbag off sig pnk, which is found in the car Saturn Sky I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign 1 voltage mass, pos sig airbag on sig ground airbag off sig pnk (1 of 1)
AIRBAG OFF SIG GROUND AIRBAG ON SIG MASS, POS SIG IGN 1 VOLTAGE
BLK/WHT WIRE
DK BLU WIRE
DK GRN WIRE
GRY WIRE
IGN 1 VOLTAGE MASS, POS SIG AIRBAG ON SIG GROUND AIRBAG OFF SIG PNK WIRE
IGN 1 VOLTAGE SENS SERIAL DATA I/P MDL SW SIG GROUND IND CTRL
INFLATABLE RESTRAINT I/P MODULE (UNDER PASSENGER SIDE OF DASH)
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INFLATABLE RESTRAINT PASSENGER PRESENCE
NCA WIRE
OFF
ORG/ WIRE
PASS AIR BAG IND
PASS SEAT BELT IND
PNK PNK WIRE
PNK PPL 3 4 5 WIRE
PNK WIRE
PPL
SHORTING BAR
STAGE 1
STAGE 2
SYSTEM (PPS) MODULE (UNDER PASSENGER SEAT)
SYSTEM (PPS) SENSOR (UNDER PASSENGER SEAT)
TAN/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> IGN 1 VOLTAGE MASS, POS SIG AIRBAG ON SIG GROUND AIRBAG OFF SIG PNK WIRE
